MMO Ruthenium Iridium Titanium Anode
Substrate: Qib 1 ntshiab titanium TA1
Ua haujlwm kub:<65 °C
Hlau nto: RuO2+IrO2
Ruthenium iridium oxide cov ntsiab lus: 8-35g/m2
Txheej thickness: 10g rau 15g raws li koj qhov kev thov
Cov khoom zoo: mesh, board, raj, pas nrig, thiab lwm yam.
Siv ib puag ncig: PH tus nqi: 0-14
Daim ntawv thov: dav siv hauv kev tsim cov NaClO.
Khoom Taw qhia
Ruthenium-iridium coated titanium anode belongs rau insoluble anode. Lub ruthenium-iridium txheej tuaj yeem ruaj khov nrog titanium substrate, nrog rau tuaj yeem txhim kho kev tiv thaiv oxidization ntawm ruthenium-platinum txheej thiab txhim kho corrosion kuj. Ruthenium-iridium coated titanium electrode yog featured nrog kev ruaj khov thiab tsis tshua muaj nqi, thiab yog nyob rau hauv daim ntawv ntawm phaj-hom electrode, raj-hom electrode, net-type electrode, bar-type electrode, hlau-hom electrode, thiab lwm yam. Ir coated titanium anode yog siv nyob rau hauv electrolysis dej, dej phwj pov tseg thiab lwm yam teb.
Ruthenium anode tseem hu ua hlau anode thiab feem ntau hu ua DSA (dimensionally ruaj khov anode) nyob hauv tsev thiab txawv teb chaws, uas coats Ru thiab Ir ntawm cov khoom titanium. Nws yog qhov paub zoo tias titanium-base platinum-plated insoluble anode feem ntau yog siv rau hauv cov hlau electrode-plating, uas muaj qhov zoo ntawm kev ruaj ntseg zoo thiab corrosion kuj thiab haum rau ntau yam nruab nrab, thiab yooj yim los tswj thiab tswj tab sis sib piv. kim. Ruthenium-iridium coated titanium anode uas tsim los ntawm Baoji City Changsheng Titanium Co., Ltd. yog kev lag luam thiab siv tau, thiab muaj cov khoom siv hluav taws xob zoo heev thiab muaj zog corrosion kuj; mmo titanium electrode yog tsim rau plating kua ntawm ntau yam nruab nrab, nrog rau siab oxygen evolution tshaj-muaj peev xwm thiab passivating kuj.
Specification
Kev ua haujlwm tam sim no:<7500A/m2
Substrate: Qib 1 ntshiab titanium TA1
Ua haujlwm kub:<65 °C
Hlau nto: RuO2+IrO2
Ruthenium iridium oxide cov ntsiab lus: 8-35g/m2
Txheej thickness: 10g rau 15g raws li koj qhov kev thov
Cov khoom zoo: mesh, board, raj, pas nrig, thiab lwm yam.
Siv ib puag ncig: PH tus nqi: 0-14
Daim ntawv thov: dav siv hauv kev tsim cov NaClO.
Ceev faj: Tiv thaiv cov khoom tawv kom tsis txhob khawb. Tshem tawm ntawm lub cell electrolytic thaum cov khoom raug tso tseg. Yaug qhov chaw nrog dej huv thiab khaws cia kom qhuav. Qhov loj dua tam sim no, lub neej ua haujlwm luv dua, thiab kev siv cov tshuaj fluoride ions yuav ua rau cov electrode puas sai sai.
Titanium anode yuav raug kuaj raws li hauv qab no ua ntej xa khoom.
Cov khoom kuaj | Kev Xeem | Cov kev cai tsim nyog |
Kev khi zog | Colorless pob tshab daim kab xev muab tshuaj txhuam | Daim kab xev tsis tso cov cim dub pom |
Φ12mm puag ncig ncej yog khoov 180 degree | Tsis peeling ntawm khoov | |
Kev xeem tsis sib xws | X-ray fluorescence spectrometer | Tsawg dua lossis sib npaug li 15% |
Txheej thickness | X-ray fluorescence spectrometer | 2-10μm |
chlorine muaj peev xwm | 2000A / m2, saturated NaCl, 25 ± 2 degree | Tsawg dua los yog sib npaug rau 1.08V |
Chlorine polarizability | 200/2000A / m2, saturated NaCl, 25 ± 2 degree | Tsawg dua lossis sib npaug li 35mV |
Txhim kho lub neej sim | 20000A / m2, 1mol / L H2SO4, 40 ± 5 degree | teev sijhawm |
Specification Case
Cov lus qhia tshwj xeeb ntawm MMO Ruthenium-iridium coated titanium anode tuaj yeem sib txawv nyob ntawm cov ntawv thov tshwj xeeb thiab cov kev xav tau.
Cov kev qhia tshwj xeeb no ua kom ntseeg tau tias MMO titanium electrode muab kev daws teeb meem zoo thiab kav ntev rau kev tiv thaiv cathodic. Lub titanium substrate muab cov khoom siv zoo heev, thaum Ruthenium Iridium txheej muab cov khoom siv hluav taws xob siab, uas pab tiv thaiv kev puas tsuaj rau cov qauv kev tiv thaiv.
Thaum tsim cov txheej txheem tiv thaiv cathodic nrog MMO Ruthenium Iridium Titanium Anodes, Ru-Ir coated titanium anode yog qhov tseem ceeb los xyuas kom meej tias cov anodes yog qhov loj thiab qhov chaw los muab kev pabcuam txaus thiab kev tiv thaiv rau cov qauv kev tiv thaiv. Qhov no feem ntau yog ua tib zoo tshuaj xyuas ntawm cov qauv hluav taws xob cov yam ntxwv thiab ib puag ncig ib puag ncig.
Zuag qhia tag nrho, qhov tshwj xeeb ntawm MMO Ruthenium-iridium coated titanium anode ua rau lawv txhim khu kev qha thiab muaj txiaj ntsig zoo rau ntau daim ntawv thov kev tiv thaiv cathodic, muab kev tiv thaiv corrosion zoo heev thiab ua haujlwm ntev.
Cim npe nrov: Ruthenium-iridium coated titanium anode, Ru-Ir coated titanium anode, mmo titanium electrode
