Sintered Lim Foamed Titanium Porous Disc
Highly resistant rau corrosion thiab tshuaj tua kab mob
Siv nyob rau hauv ib puag ncig hnyav
Khaws thiab tuav cov khoom me me
Zoo meej rau lim tawm cov khoom me me
Siv rau hauv kev lag luam aerospace
Khoom Taw qhia
Khoom taw qhia
Titanium hmoov porous lim discs yog siv nyob rau hauv ntau yam kev lag luam, xws li aerospace, tsheb, khoom noj khoom haus thiab dej haus, thiab kev kho mob. Lawv yog tsim los ntawm cov hmoov zoo titanium thiab zoo meej rau lim tawm cov khoom me me, xws li plua plav thiab av. Nws yog tsim los ntawm kev tsim cov porous matrix ntawm titanium hmoov, uas yog ces sintered ua ke. Qhov no tsim cov lim dej uas muaj zog thiab ruaj khov uas tuaj yeem ntes thiab tuav cov khoom me me, thaum tseem tso cai rau huab cua thiab kua kom dhau mus. Nws kuj tseem tiv taus corrosion thiab tshuaj tua kab mob, ua rau lawv zoo tagnrho rau siv nyob rau hauv ib puag ncig hnyav.
Khoom siv: Titanium & Stainless Hlau & Nickel / Bronze
Daim duab: Phaj / ntawv / disc
1) Pom tus nqi: 0 5-70μm
2) Pore loj: 1-200μm
3) Porosity: 20-50 feem pua
4) Thickness: ＞ 0.5mm los yog raws li koj xav tau
5) Txoj kab uas hla: φ5mm -320mm
6) Ntev: L100mm-1200mm
6) Kub ua haujlwm: 250 / 500 / 800 degree (ntub)
7) Ua haujlwm siab tshaj plaws: 0.6MPa
Nco tseg: Tshwj xeeb tshwj xeeb tuaj yeem kho tau
Khoom siv: Titanium & Stainless Hlau & Nickel / Bronze
Puab: Qws / Tube / Cap thiab lwm yam
7) Pom tus nqi: 0 5-70μm
8) Pore loj: 1-200μm
9) Porosity: 20-50 feem pua
10) Phab ntsa Thickness: ＞ 2.5mm lossis customized
11) Txoj kab uas hla: φ8mm -320mm
12) Ntev: L100mm -1200mm (tsis muaj vuam)
6) Kub ua haujlwm: 250 / 500 / 800 degree (ntub)
7) Ua haujlwm siab tshaj plaws: 0.6MPa
Nco tseg: Tshwj xeeb tshwj xeeb tuaj yeem kho tau
Lwm yam kev ua
>Machining ntau yam interfaces (connector)
>Ua txheej txheej ntawm lub phaj ntxeem tau: xws li iridium ruthenium, iridium tantalum, platinum txheej thiab lwm yam.
Hlau hmoov sintered ntxeem tau lim caij technical parameters | |||||
Qib | Lim tus nqi (μm) | Pore loj Max (μm) | Porosity (%) | Permeability M³/h.㎡.kpa | Compression zog Mpa / cm² |
T1 | 60μm | 180μm | 30 feem pua -40 feem pua | 800 | 2.5 |
T2 | 30μm | 100μm | 30 feem pua -40 feem pua | 500 | 2.5 |
T3 | 20μm | 60μm | 30 feem pua -40 feem pua | 250 | 2.5 |
T4 | 10μm | 30μm | 30 feem pua -40 feem pua | 120 | 2.5 |
T5 | 5μm | 15μm | 20 feem pua -30 feem pua | 40 | 2.5 |
T6 | 2μm | 10μm | 20 feem pua -30 feem pua | 15 | 3.0 |
T7 | 1μm | 6μm | 20 feem pua -30 feem pua | 5 | 3.0 |
T8 | 0.5μm | 4μm | 20 feem pua -30 feem pua | 3 | 3.0 |
T9 | 0.2μm | 2.5μm | 20 feem pua -30 feem pua | 1.5 | 3.0 |
Khoom Feature
>High filtration efficiency.
>High mechanical zog.
>High permeability thiab porosity.
>Anti-corrosion thiab anti-siab.
>Txawm tias faib cov pores catalysis rov ua dua qhov tseeb lim.
>Yuav siv tau ntawm qhov kub thiab txias.
>Yooj yim ntxuav thiab tuaj yeem siv tau ntau zaus.
>Lub neej ua haujlwm ntev.
Khoom siv
1. Kev sib cais thiab pom cov kua thiab roj.
2. Acid thiab alkali pom.
3. Kev lag luam hluav taws xob: hluav taws xob, micro-electronics, semiconductor kev lag luam dej.
4. Kev lag luam kev kho mob: cov khoom siv raw khoom muag, cov kuab tshuaj kho mob decarbonizing.
5. Kev lag luam tshuaj: rganic hnyav, tshuaj reagent raw khoom ua kua catalyst.
6. Kev lag luam zaub mov: npias, dej haus, dej ntxhia, roj zaub, kua ntses, vinegar.
7. Roj refining kev lag luam: pub rov qab dej rau roj teb, ua ntej lim ntawm rov qab osmosis nyob rau hauv seawater desalination teb.
Cim npe nrov: Foamed Titanium Porous Disc, Sintered Lim Porous
